| SPECIFICATIONS | UNIT | VMS200 |
|---|---|---|
| Swing Over Bed | MM | 500 |
| Standard Turning Dia | MM | 200 |
| Max Turning Dia | MM | 370 |
| Max Turning Length | MM | 470 |
| Slides | ||
| X Axis Travel (Cross) | MM | 190 |
| Z Axis Travel (Longitudinal) | MM | 520 |
| Rappeed Feed (X & Z Axis) | MM/M | 20/20 |
| Main Spindle | ||
| Spindle Motor Power | Kw | 7.5Kw |
| Spindle Speed Range | RPM | 50-3000 |
| Spindle Bore | MM | 65 |
| Spindle Nose | A2-6 | |
| Max Bar Capacity | MM | 51 |
| Turret | ||
| No. of Station | 8 | |
| Max. Boring Bar Capacity | MM | 40 |
| Tool Size (Cross Section) | MM | 25 x 25 |
| Tail Stock | ||
| Quill Dia | MM | 80 |
| Quill Stroke | MM | 100 |
| Thrust | KGF | |
| Accuracy | ||
| Positioning | MM | 0.008 |
| Repeatability | MM | 0.005 |
| Other Data | ||
| Machine Weight | KG | 3600 |
| Machine Dimension | L X W X H | (2615 x 1950 x 1685) |
