| Technical Specification | |||
|---|---|---|---|
| Max. Swing Over Bed | kW | 500 | |
| Chuck Dia | mm | 250 / 300 | |
| Standard Turning Dia | mm | 260 | |
| Max. Turning Dia. With Limited Length | mm | 450 | |
| Max. Turning Length | mm | 500 | |
| Max Bar Capacity | mm | 50 / 60 | |
| Spindle | |||
| Spindle Nose | A2-6 | ||
| Spindle Bore | mm | 65 | |
| Spindle Speed Range | RPM | 50–3000 | |
| Spindle Motor Power (Cont/30min) | kW | 11 | |
| Axis Detail | |||
| Rapid (X & Z Axis) | m/min | 20 | |
| Ball Screw (Z-Axis) | mm | 40×10 | |
| Ball Screw (X-Axis) | mm | 32×10 | |
| LM Guide (Z Axis) | mm | 45 | |
| LM Guide (X Axis) | mm | 35 | |
| Turret | |||
| No. of Stations | 8 | ||
| Tool Size (Cross Sectional) | mm | 25 × 25 | |
| Maximum Boring Bar Diameter | mm | 40 | |
| Tail Stock | |||
| Quill Dia | mm | 80 | |
| Quill Stroke | mm | 100 | |
| Accuracy | |||
| Repeatability | mm | 0.01 | |
| Positioning | mm | 0.005 | |
| CNC System | |||
| Controller | Siemens 808D Advance | ||
| Machine Size | |||
| Dimension (L x B x H) | mm | 2700 × 2050 × 1770 | |
| Machine Weight (approx.) | kg | 4800 | |
